Tower Crane Anemometer Wind Speed Meter

Description:

FC-300A/FC-002A wind speed alarm is composed of Intelligent measuring and controlling host, and wind speed sensor cable consists of three parts. Intelligent measuring and controlling host microcontroller and the external circuit module.


Product Details

FC-300A/FC-002A wind speed alarm is composed of Intelligent measuring and controlling host, and wind speed sensor cable consists

of three parts. Intelligent measuring and controlling host microcontroller and the external circuit module, displaying part employ highlight

digital display. Marine military high-precision measurement of the wind speed sensor speed sensor, compared with traditional products,

with high precision and wide measuring range, high input line resistance, ease of observation, stability and reliability.


An overview, anemometer uses:


typeFC-300A/FC-002A
Working voltageAC220V±10% or DC24V
Response time＜1S
Measuring range0~70m/s
Resolution0.1 m/s
Precision3%
Transmission distance＞1㎞
Measuring range0~60m/s
The ambient temperature-40~85℃
Display1 inch LED digital display (24-hour lights without compensation)


Alarm settings1、the alarm can be set

2、level alarm for green tips and normally open or normally
closed switch signal output
3、the second alarm to sound and the Red alarm and outputs normally
open or normally
closed switch signal
4、level alarm and the secondary output of the alarm outputs are respectively
Wind speeds/windWind speed and wind can switch display

  • Wind-speed transmitter is a device that records the route of wind, observe instantaneous wind speed and wind force,
    which is used in construction, weather station, chemicals, power station, industrial and mining enterprises.
    microcomputer intelligent digital wind-speed transmitter can realize wind speed indicating digitization and automation. It is an indispensable
    modern equipment for related equipment.
    FC-300A/FC-002A wind speed alarm with cranes (cranes, crawler cranes, Portal cranes, tower cranes, etc), railway, ports, docks,
    power plants, environment, meteorology, ropeway, greenhouses, aquaculture and other devices used to measure wind speed in the field.
    Used to speed indicates the digitization and automation of equipment, associated equipment indispensable wind speed detecting equipment.


This product electronic technology, microcomputer technology as a whole. Its main functions are as follows:

A, and enter the instrument can automatically detect the wind speed signal processing, shows the wind speed or wind scale

B, the instrument can automatically alert the pre-set parameters. For example: preset speed alarm value and control power functions

C, when the wind speed exceeds a preset time, automatically sound and light alarm, and issue control commands (power off the device and cause the device to stop working).

Display dataWind-speed and wind scale double rows display
PowerAC 220V±10% 50HZ
Insulating power≥10MΩ
Exterior size155mm×155mm×60mm
Power consumption≤15W
Alarm wind scale settingAlarm wind scale default 4 grade


Tower Crane Anemometer Wind Speed Meter Selection Notes

Tower Crane Anemometer Wind Speed Meter is listed for buyers who need reliable lifting or access equipment for construction, facade work, maintenance or replacement service. Before confirming an order, match the product with the actual machine model, site height, rated load, power supply and installation conditions.

For related options, browse our tower crane accessories or contact the technical team with drawings, photos, nameplate information and working conditions.
